New Fabrication Technique Leads to Broader Sunlight Absorption in Plastic Solar Cells

Schematics of Sequentially Cast Ternary (SeCaT) solar cell. Image: Peter and Ryan Allen

For Immediate Release

Researchers from North Carolina State University have developed a new strategy for fabricating more efficient plastic solar cells. The work has implications for developing solar cells with a wider absorption range and increased efficiency.

As plastic solar cells now rival silicon-based solar cells in power conversion efficiency, researchers want to increase the range of photonic energies that plastic solar cells absorb. Ternary solar cells, in which three materials are mixed together as a light-harvesting layer, offer a potential solution. However, while ternary solar cells have been manufactured for years, most of the devices have not been able to meet desired levels of performance ­– mainly due to unfavorable mixing.

Masoud Ghasemi, a graduate student in physics at NC State and lead author of a paper describing the research, worked with a team of other NC State physicists led by Harald Ade and chemists from the University of North Carolina at Chapel Hill led by Wei You to identify a way to solve the production problem.

The team proposed a calorimetric tool to study the morphology of a ternary system with two absorption-matched donor polymers and a fullerene acceptor. When fabricated by the traditional method – which involves mixing all three materials together and then depositing them onto a substrate – the system gave poor device performance.

“Using thermodynamic techniques, we were able to find that this particular mixture was undergoing ‘alloying,’ in which the donor polymers tend to group up together and push the fullerene away,” Ghasemi says. “This explains why so many conventionally produced ternary cells may have low efficiency.”

The team decided to solve the alloying problem by mixing each polymer separately with the fullerene, rather than mixing all three materials together at once. They created two distinct mixtures which were layered onto the substrate, creating sequentially cast ternary (SeCaT) solar cells, which did not fall prey to alloying.

“The SeCaT solar cells prevent the polymers from mixing due to their layered structure,” Ghasemi says. “This novel design allows fabrication of plastic solar cells with wider optical sensitivity using cheap and scalable processing steps and with reduced materials selection constraints. Hopefully this new method can be particularly useful for greenhouse applications toward zero energy farming, as the materials used to demonstrate our method have optical properties compatible to these applications.”

The work appears in Advanced Materials. Harald Ade, professor of physics at NC State, is corresponding author. NC State assistant research professor Abay Gadisa, postdoctoral scholars Long Ye, Joo-Hyun Kim and Omar Awartani, as well as UNC-CH postdoctoral scholar Liang Yan, graduate student Qianqian Zhang, and associate professor of chemistry Wei You, also contributed to the work. The research was funded by the Office of Naval Research grant N000141512322.

-peake-

Note to editors: An abstract of the paper is below

“Panchromatic Sequentially-Cast Ternary Polymer Solar Cells”

DOI: 10.1002/adma.201604603

Authors: Masoud Ghasemi, Long Ye, Joo-Hyun Kim, Omar Awartani, Abay Gadisa, Harald Ade, North Carolina State University; Liang Yan, Qianqian Zhang, Wei You, University of North Carolina at Chapel Hill
Published
: Advanced Materials

Abstract: Sequentially cast ternary method is developed to creat stratified bulk heterojunction (BHJ) solar cells, in which the two BHJ layers are spin cast sequentially without the need of adopting middle electrode and orthogonal solvents. This method is found to be particularly useful for the polymers that form mechanically alloyed morphology due to high degree of miscibility in the blend.
